DEYE 48V Low Voltage 5KW 6KW 8KW 10KW Hybrid Inverter Split Phase
The DEYE SUN8K-SG01LP1-US is an advanced split-phase hybrid grid-tied inverter developed by DEYE. It is designed to provide reliable and efficient power conversion for residential and commercial solar energy systems, combining multiple features to optimize energy production and system performance.With the frequency droop control algorithm, this series product supports Max. parallel units up to 16pcs.
Important Specification of DEYE Split Phase Hybrid Inverter
| Model | SUN-5K-SG01LP1-US | SUN-6K-SG01LP1-US | SUN-8K-SG01LP1-US/EU |
| Battery Input Data | |||
| Battery Type | Lead-acid or Lithium-ion | ||
| Battery Voltage Range (V) | 40~60V | ||
| Max. Charging Current (A) | 120A | 135A | 190A |
| Max. Discharging Current (A) | 120A | 135A | 190A |
| Charging Curve | 3 Stages / Equalization | ||
| External Temperature Sensor | Yes | ||
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS | ||
| PV String Input Data | |||
| Max. DC Input Power (W) | 6500W | 7800W | 10400W |
| Rated PV Input Voltage (V) | 370V(125V～500V） | ||
| Start-up Voltage (V) | 125V | ||
| MPPT Range (V) | 150V-425V | ||
| Full Load DC Voltage Range (V) | 300V-425V | 200V-425V | |
| PV Input Current (A) | 13A+13A | 26A+13A | 26A+26A |
| Max. PV ISC (A) | 22A+22A | 44A+22A | 44A+44A |
| Number of MPPT Trackers | 2 | ||
| Number of Strings per MPPT Tracker | 1 | 2+1 | 2 |
Key Advantages
The SUN5K/6K/8K-SG01LP1-US inverter offers a range of benefits for solar installations. It is specifically designed to convert the DC (direct current) power generated by solar panels into AC (alternating current) power that can be used by the electrical grid or consumed on-site. This enables efficient energy conversion and ensures that the solar system operates optimally.
One of the key advantages of the SUN5K/6K/8K-SG01LP1-US inverter is its hybrid functionality. It allows for both on-grid and off-grid operation, providing flexibility and reliability even in remote or unstable grid environments. In case of a power outage, the inverter can seamlessly switch to off-grid mode and continue powering essential loads using battery storage, ensuring uninterrupted power supply and maximizing self-consumption.
The SUN5K/6K/8K-SG01LP1-US inverter incorporates advanced MPPT (Maximum Power Point Tracking) technology, which maximizes energy production by constantly tracking and adjusting to the optimal operating point of the solar panels. This ensures that the inverter operates at its peak efficiency, maximizing power generation and delivering higher overall system performance.
Installation of the SUN5K/6K/8K-SG01LP1-US inverter is made easy with its user-friendly design. The inverter features a compact and lightweight form factor, making it easy to handle and install. It also comes with plug-and-play connectors and a simplified wiring system, reducing installation time and costs.
The SUN5K/6K/8K-SG01LP1-US inverter offers comprehensive monitoring and control capabilities. It can be easily integrated with DEYE's monitoring platform, allowing users to remotely monitor the system's performance, energy production, and battery status in real-time. This enables proactive system management, efficient troubleshooting, and optimal system optimization.
Safety is a top priority for DEYE, and the SUN5K/6K/8K-SG01LP1-US inverter incorporates various safety features. It is compliant with international safety standards and includes built-in protection mechanisms such as overvoltage, overcurrent, and short-circuit protection, ensuring the safety of the system and its users.
The SUN5K/6K/8K-SG01LP1-US inverter is designed for long-term reliability and durability. It is built using high-quality components and undergoes rigorous testing to ensure robust performance in various environmental conditions. This ensures that the inverter can withstand harsh weather conditions and operate consistently over its operational lifespan.
Warranty and Support
We stand behind the quality and reliability of our products. The DEYE split phase hybrid grid inverter comes with a comprehensive warranty package and dedicated technical support, ensuring customer satisfaction and peace of mind.
Generally speaking, we offer you 5 years of warranty. If there’s any quality problem, just contact our technical team.
